2 Phase 4 Wire Stepper Driver 2 in 1 Bipolar Stepper Motor Drivers Photoelectric Isolation

1、2 Part Composition: Composed of 2 parts driver and wiring. 2 general 2 phase stepper drivers are integrated in one driver shell reduces the volume keeps the functional characteristics unchanged and saves space and wiring 2、Photoelectric Isolation: 2 different pulse + direction + enable control signals can be input at the same time to control the operation of 2 different motors without interference. The input signals are all photoelectric isolation 3、Basic Specifications: In order to ensure the stability of the system the wiring adopts 2.54mm standard sockets the flat cable uses single PH header 24 wire the length is 300mm and the signal wiring uses 26 wire 4、Applicable Motor: The stepper motor driver is suitable for 24 28 35 29 42 57 and other 5 wire 6 wire 8 wire and other 2 phase micro stepping motors 5、Detect the Temperature: The external temperature protection probe is 10K (NTC) to detect the temperature between ?10 and +75℃ . The probe can be fixed to the motor solenoid valve or battery
