2 Megapixel OV2640 Camera Module with Adapter Board STM32 /C51 Driver

Overview With 2 million pixels 1632x1232 pixels the OV2640 image sensor is small in size and low in operating voltage providing all the features of a single UXGA camera and image processor Through the SCCB bus control it is possible to output 10 bit sample data of various resolutions such as full frame sub sampling and window The UXGA image of this product is up to 15 frames per second Users have complete control over image quality data format and transmission All image processing functions including gamma curve white balance saturation chrominance etc can be programmed via the SCCB interface OmmiVision Image Sensors use unique sensor technology to improve image quality and reduce sharp and stable color images by reducing or eliminating optical or electronic defects such as fixed pattern noise tailing and floating Features ● High sensitivity for low illumination applications● Low voltage for embedded applications● Standard SCCB interface compatible with I2C interface● RawRGB RGB GRB4 2 2 RGB565 555 444 YUV 4 2 2 and YCbCr 4 2 2 output formats● Support UXGA SXGA VGA QVGA QQVGA CIF QCIF and various sizes up to 40x30 size● Support VarioPixel subsampling mode● Automatic influence control functions include automatic exposure control automatic gain control automatic white balance automatic elimination of light streaks automatic black level calibration Image quality control including color saturation hue gamma sharpness ANTI BLOOM●ISP
