2 Channel RF Wireless System Remote Control Switch Module with Shell 12V 10A 315MHz for Smart Home

Descriptions: Channel: 2 CH 2 channel work way Decode: Learning code Working Voltage: DC 12V Output way: Momentary defaults ,(other model can change by yourself in work pin) Maximum Load Current: 10A Relay load:10A 220/110V Receiver Sensitivity: -105dBm Working temperature : -40'C - +80'C Size: 68mm x 48mm x 15mm Working Model /output way(change method): The Work model can change in the switch board work pin.(1.Jog/momentray:All Model-pin not connector. 2.Self -lock/Self-Latched: Model (pin1+Pin 2) Connector Or (Pin2+pin 3) connector.3 Inter-lock /Latched:(Pin2+pin 3) Or (Pin1+Pin2) Connector) 1. Jog/momentray: Press one button is Working /ON. Loosen your finger on the same button is Stop/OFF. One channel switch need one buttons remote control. 2.Self -lock/Self-Latched: Press one button for one time is working/ON. Press the same button again is stop/OFF. One channel switch need one buttons remote control. 3.Inter-lock /Latched: Press one button is working/ON, press another button is stop/OFF. One channel switch need 2 buttons remote control. Add remote control method: 1. Connector the switch to 12V... 2. press the switch board learn button (1-3 second),till the switch LED lighting.. 3. after press the remote control button(A.B) till the switch LED lighting.. the relay will be ON or OFF. 4. test the controller control the switch.. press the control button, the relay will be on and off.. you can hear it. Remove Remote control: 1. Connector the switch to 12V .. 2. Press the learning button for about 8 seconds, the indicator light turns on to off, then the code you learned before will be deleted.The remote controller can not control the switch relay. Package Included: 1 x 2 Channel RF Wireless System Remote Control Switch with Shell
