1pcs/lot RS232 / SPI HighSpeed JPEG Serial Port CCTV Camera Module SCC-1 with video out support VC0706 SPI/Serial Protocol

1pcs/lot RS232 / SPI HighSpeed JPEG Serial Port CCTV Camera Module SCC-1 with video out support VC0706 SPI/Serial Protocol
thumb
thumb
thumb
thumb
thumb
thumb
sku: 1975849841
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$25.00
Shipping from: China
   Technical Details
Brand Name: VDUNSKY
Connectivity: Closed System/CCTV Wired
Frame rate / CVBS Output: 60fps / Support
High Definition: None
Imange Sensor: 1/5" CMOS, 300000 pixels
Lens mm: 2.8mm
Model Number: SCC-1
ODM /OEM: Support
Picture format: VGA,QVGA,QQVGA ,CIF,QCIF,QQCIF
Power ConsumptionW: 90mA
Sensor: CMOS
Serial Protocol: VC0706 Serial port Protocol
Special Features: TTL / SPI
SPI Band rate: Default (13.5Mbps) ,0.211/0.422/0.844/1.688/3.375/6.75/13.5Mbps)
SPI Protocol: VC0706 SPI Protocol
Style: camera moudule
Supported Operating Systems: Windows Vista,Windows 7,Windows 98,Windows XP
Technology: Infrared
Two Communication modes: TTL / SPI
Type: Video Camera
UART Band rate: Default (38400), 9600~115200 bps
Working voltage: 5 V (Optional 3.3V, Remove the 3.3V DC Chip and Connect ) )
