1MHz-1000MHZ 35DB RF Power Amplifier 3W HF VHF UHF FM Transmitter Broadband For Ham Radio

Application This Broadband RF power amplifier suitable for all kinds of radio FM radio remote control toy radio and so on the input of 1 MW 0DBM maximum output of 3 watts 15V voltage power supply broadband 1MHZ to 1000MHZ can work Because of the excellent design in low frequency can reach 35DBM 3W when 500M the output power can reach 32DBM 1 6W Power amplifier size 37MMx56CMx1 5CM behind with a large heat sink Color greenMaterial metal Technical indicators 1 Supply voltage 15V DC typical current value 450mA maximum gain output 2 The working frequency 1MHZ 1000MHZ input and output impedance 50 ohms 3 The maximum output range 35dbm 3W 50 ohms 4 Gain 35 dB see the specific curve S21 curve there are differences between different frequency 5 The input signal size low frequency band 0DBM 1 mW high frequency band 2DBM Package included 1 x 1MHz 1000MHZ 3W HF VHF UHF FM transmitter RF Power AmplifierOnly the above package content other products are not included Note Light shooting and different displays may cause the color of the item in the picture a little different from the real thing The measurement allowed error is 1 3cm Package includes 1 x RF amplifier
