180W Constant Current Electronic Load 200V 20A Battery Tester USB Discharge Capacity Tester Module Measuring Tools

Description: 180W Electronic Device Tester Continuous Load Discharge To test electronic devices function voltage and maximum current Features: -- Take-all Measurement, can be used as electronic constant current load, battery, USB tester, cable detector -- Real-time monitoring to test, safe discharge -- Dual Adjustment power electronic load continuous discharge -- Built-in intelligent temperature control and large power auto protection -- Support Qual comm QC2.0 compatible QC3.0 quick voltage range test -- One screen with multi Display, Voltage, Current, Capacity, Power and Timing display Specification: Power Supply Voltage: DC6-12V Power Supply Interface: DC 5.0 or Micro USB Voltage Testing Range: 0.00V~200V; Resolution Accuracy: 0.05V Current Adjustable Range: 0.00A~20A; Resolution Accuracy: 0.05A Capacity Measure Range:0~999.999Ah; Resolution Accuracy: 0.01Ah Electricity accumulated range: 0~9999.9Wh; Resolution Accuracy:0.01Wh Impedance Measure Range:1~999.9ohm; Resolution accuracy: 0.01ohm Power measure Range: 0~2999.99W; Resolution Accuracy:0.01W Temperature Range: 0~99; Resolution accuracy: 1 Max. Timing: 999 hours 59minutes 59 seconds; Resolution accuracy:1s Over voltage over current setting alarm method: Display warming, voice alarm users Display screen type: Micro Power Consumption, LCM Module, Black font, Green backlight Refresh time: >500mS/times Measure Rate: about 2s/time Protecting voltage setting range:1~300V Low voltage setting range:0~149V Protecting current setting range: 0.2~100A Protecting Power setting Range: 185W Size: approx. 160mmx95mmx60mm Operating Temperature: -10~+60 Operating Humidity: 10~80 (no condensation) Working Gas Pressure:80~106kPa Kindly Note: 1. You need to test Qual comm QC2.0/QC3.0 quick voltage (5V, 9V, 12V, 20V) and requires a combination of our QC2.0/QC3.0 trigger can test, can directly read Qual comm QC2.0/QC3.0 fast charging voltage (5V, 9V, 12V, 20V). 2. Due to different product batch, Yellow or Green color Board will be sent at random Usage Method: Keystrokes using method and the capacity, power,time reset Settings: 1) Reset button long-press all data (mAh,Wh,00:00:00) 2) Quickly button twice - capacity Reset (mAh) 3) Quickly button three - power reset (Wh) 4) Quickly button four - time reset (00:00:00) 5) Quickly button five - Set up automatic standby and Discharge the countdown to remind regularly 6) When no load output no-load,quick seven keys,and for the current zero to zero in the current environment temperature for accurate calibration,so more can do more accurate measurement in small current. Package Included: 1x Electronic Load Power Tester 1x Charger 2x Aligator clip Cable 1x USB Aligator Clip
