16x16mm TeenyF3 Pro Flytower F3 OSD Flight Controller w/ Buck-Boost Converter & 5A BL_S DShot600 ESC
Eachine1
sku: 1326938
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$29.78
Shipping from: China
Description
TeenyF3 Pro Flytower F3 FC AIO OSD Buck-Boost Converter & 5A BLheli_S DShot600 1-2S 4 in 1 ESC Specification: Flight Controller (Top) Item Name: TeenyF3 Pro flight controller board Model: TeenyF3 Pro Input Voltage: 1-2S Lipo Processor: STM32F303CCT6 (72MHZ, 256K FLASH) Sensor: MPU-6000 (connected by SPI) Firmware version: betaflight_3.1.7_OMNIBUS - Built-in Betaflight OSD - Built-in Buck-Boost Converter Receiver: PPM, Spektrum 1024/2048, SBUS, IBUS, XBUS SumD SumH RX etc. Size: 20*20mm Mounting Hole: 16*16mm Hole Diameter: 2mm ( M2 ) Weight: 2.1g Application: for 60mm-80mm mini brushless FPV drone 4 in 1 ESC (Bottom) Item name: Teenypro 5A 4 In 1 BLHeli_S ESC Model: Teenypro Con. Current: 5A Peak Current: 7A (5S) Input Voltage: 1-2S Lipo Firmware: BLHELI_S Processor: SILABS EFM8BB21F16G BEC: NO Size: 23x27mm (include solder pad) Mounting Hole: 16x16mm ( M2 ) Weight: 2.1g Support Dshot150, Dshot300, Dshot600, Oneshot125, Multishot PWM Firmware Target: BLHeli_S S_H_50_REV16_7 Features: - Support programmable LED_Strip - Support BLheli/BLHELI_S suite Pass-through ready - Support PPM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600 - Default Dshot600 ready - Built-in voltage detection, alarm - Built-in Betaflight-OSD - Buzzer solder pin - LED_STRIP solder pin Package Included: 1x F3 Flight Controller Board 1x 5A 4 in1 ESC 8x M2*5+5 Nylon Column 8x M2 Nuts 8x M2 Screw 1x 6P Cable
