15/25cm PCB Ruler Measuring Tool Resistor Capacitor Chip IC Electronic Straight Scale Engineering Ruler

Description 15 25cm PCB Ruler Measuring Tool Electronic Engineering Ruler Specification Material PCBCentimeter side 0 1cm marksSize 15CM 25CM Optional Font size guide trace width diagram and a set of AWG sized drills Front Commonly used IC package 1 NAND FLASH TSOP482 QFP7X7 643 PLCC 204 SOP165 TSSOP246 SSOP87 SOP8Commonly used CHIP component 1 TO252 32 SOT2233 SOT89 34 SOT23 6 5 SOT23 36 SOD1237 SOD3238 12109 352810 120611 0805 12 060313 040214 TO92Common bore diameter reference dimensions unit mm 3 02 52 01 51 00 80 50 4 Back Commonly used line width reference unit mm Angle Measurement 180 degreesDevice IC pin spacing table 0 5mm 0 65mm 0 8mm 1 0mm 1 25mm 2 54mm Common bore diameter reference dimensions unit mm 3 02 52 01 51 00 80 50 4 Features In addition to measuring the basic functions of millimeter and inch sizes it also integrates relevant information for PCB design such as angle gauges devices IC pin spacing tables Resistor and capacitor chip package the commonly used diameter reference drill line width size reference High strength and hardness Ideal tool for electronic enthusiasts Package Included 1Pcs x PCB engineering ruler More Details
