14Pcs Universal FPC/LVDS Display Cable Support For 10-65 Inch Screen LCD Controller Board

Specifications: Fit For: 10-65 inch screen Color: as pictures Socket Length: 20mm, 30mm Name: Screen cable Model: 602368 Features: 1. Drive board common, support 10-65 inch screen monitor repair, commonly used LCD LVDS screen line. 2. The general board LVDS interface 30 pin is basically defined as follows: 1 2 3 power supply 4 5 6 ground wire 7 8 9 10 11 12 Three sets of data lines (00- 00+ 01- 01+ 02- 02+) 13 14 ground line 15 16 clock lines (0C- 0C +) 17 18 (03 - 03+) Here is a single 8 commonly used five groups. 19 20 21 22 23 24 Three sets of data lines (0E- 0E + E1-E + E2- E2 +) 25 26 ground wire 27 28 clock line (EC-EC +) 29 30 data lines (E3- E3 +) Model: 1 x DF14-20Pin-S6 1 x DF14-20Pin-S8 1 x FIX-30Pin-S8 (power on left) bit 1 x FIX-30Pin-S8 (power on right) bit 1 x FIX-30Pin-D6 (power on left) bit 1 x FIX-30Pin-D8 (power on left) bit 1 x FIX-30Pin-S8 (power on left) bit (for 17''-42'' screen) 1 x FIX-30Pin-S8 (power on right) bit (for 17''-42'' screen) 1 x FPC-LVDS-30Pin-S8 (power on left) bit 1 x FPC-LVDS-30Pin-S8 (power on right) bit 1 x LP-40Pin-S6 (LED laptop SD) 1 x LP-40Pin-D6 (LED laptop HD) 1 x FIX-51Pin-D8 (power on left) bit (Most universal LVDS cable for 32''-65'' screen) 1 x FIX-51Pin-D8 (power on right) bit (Most universal LVDS cable for 32''-65'' screen) Note: Due to the manual measurement, there might be some error. Package included: 14 x screen cable
