14 Pin Metal Male Plug 136961 141162 Connector for Miller Hobart TIG MIG Welder

Features: brand new high quality Fits Miller TIG welders. The 14-pin connection is designed for use with many welders and has a variety of functions including remote current control and remote wire feeders. Rugged metal construction for maximum durability. Easy installation and stable performance. Product parameters: Number of needles: 14 Pin Diameter: 1.6mm Thread: 1-1/8 -18 UNEF 2B Ambient temperature: -55°C ~ +100°C Relative humidity: When +44°C±2°C the relative humidity is 90%~95% Working current (per pin): 10A Rated voltage: 200V Insulation resistance: ≥1000MΩ Tangential resistance: ≤20MΩ Overvoltage: 1000V Mechanical life: 500 times Package Included: 1 * 14 pin male plug Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data.
