13S 35A 48V Li-ion Battery Protection Board BMS PCB with Balance For E-bike Scooter

Description: With a balanced Overcharge protection Over discharge protection Over current protection Short circuit protection Temperature protection Specification: Name: 13S 35A 48V Protection Board with Balance Size: 69*51*8mm Cable Length: 300mm Charging current: 8A Electrical parameters: As shown in following table Electrical Parameters: (13 string split-mouth) Detail Specifications Tipical Unit Discharge Continuous Discharging Current 35(Max) A Instantaneous Discharge Current 100 A Charge Charging Voltage 54.6 V Charging Current 8(Max) A Overcharge Protect Over-charge Detect 4.280.05 V Protect Delay 100 mS Over-charge release 4.080.05 V Balance Detect Voltage 4.20.025 V Release Voltage 4.20.05 V Balance Current 605 mA Over-discharge Protect Over-discharge Detect 2.550.08 V Over-discharge Detect delay 50 mS Release Voltage 3.00.1 V Over-current Protect Detect Voltage 150 mV Detect Delay 15 mS Current Detect 1200.5 A Release Condition Cut Load Short-circuit Protect Protect Condition External load short circuit Detect Delay 200 uS Release Condition Cut Load Temperature Protect Temperature Protect / Resistance Inner 15 m Self-Consumption Working Current 50 uA Sleep Current (when Over-discharge) 10 uA Working Temperature Range -30/+80 Package Included: 1 X Battery Protection Board
