12V Governor ESD5500E Series Electronic Engine Speed Controller +ADC120 Actuator

Alternator Generator Governor Actuator ADC120-12V ESD5500E MSP6729 Speed Sensor Description: Brand New ESD5500E Series Speed Governor Item Specifics: ●ESD5500E series speed governor is high cost effective the best quality large stock lower price perfectly electric speed governor. ●Widely used to all kinds of generator together with ADC120 12V high performance and perfectly realize electronic speed governor. Color: As shown in picture Package Included: 1x ESD5500E speed controller 1x MSP6729 Magnetic Speed Sensor 1x ADC120 actuator Speed Sensor MSP6729 Specifications: Inductance：142MH+25% Resistance：300 Ohms Maximum Thread Size: 3/8-24UNF-2A Proximity to Gear Teeth：0.025-0.035in.(0.64-0.89mm.) Temperature Range：-55℃ to 105℃ IDLE Ouput：1.5 volts AC minimum Max Output：30 volts AC ADC120-12 Actuator SPECIFICATIONS PERFORMANCE: Available Torque Max1.0Lb-ft(1.4Nm) Maximum Operating Shaft Angular Travel 25+1degree CW/CCW POWER INPUT: Operating voltage 12V DC Normal Operating Current 2 A at 12V DC 1 A at 24VDC Maximum CurrentContinuously Rated 6 A at 12V DC 3 A at 24VDC ENVIROMENTAL: Temperature Range -54 to 95 Relative Humidity up to 100% All Surface finishes Fungus proof and corrosion resistant PHISICAL: Weight 2.3 kg Mounting Any position electrical connector at the top preferred RELIABILITY: Vibration up to 20G @50-500 Hz Testing 100% Tested MATING HARDWARE: Connector Supplied With Actuator Lever LE1500-2 Rod End Bearings(to attach a 12#20 HD linkage rod to lever) BR100(Right Hand)
