12V/24V 1000W Waterproof Wind Turbine Generator Charge Controller Regulator

Features: *This product is a smart controller that combined solar energy controlling and wind energy controlling. *It is designed for high-end small Wind & Photovoltaic for Hybrid especially suitable for wind-photovoltaic for Hybrid power generation and wind-photovoltaic for Hybrid monitoring . *It can control the wind turbines and solar panels simultaneously to charge the battery safely and efficiently. The device has a nice appearance clear instructions and convenient . It also has a comprehensive series of protective measures. Specifications: Name:12V/24V 400W/800W Waterproof Wind And Light for Hybrid Controller Model:B26387 Material:Aluminium Alloy Application:Wind Power Photovoltaic Controller Color:Black Product Model: ECO-400 Battery Nominal Voltage: DC12/24V Rated Power of Wind Turbine: 400W/800W Lock Voltage of Wind Turbine: 14.5V/29V Recovery Voltage of Wind Turbine:13.2V/26.4V Rated Power of Solar Power: 500W/1000W Maximum Discharge Current: 20A Static Power: 15mA Working Temperature: -35~+75degree Celsius Size:approx. 130mm×82mm×21mm Level of Protection: IP67 Performance: Reliability: Intelligent modular design simple structure powerful functions; Industrial grade high-quality components and strict manufacturing techniques which is suitable for relatively harsh working environments such as low temperature. It also has reliable performance and long service life. Mode of Connection: 1. Firstly connect the positive pole of the load battery and solar panel to the red line of the controller. 2. Then connect to the load s yellow wire of the negative pole. 3. Then connect the negative pole of the battery to the black line of the controller. 4. Connect the negative pole of the solar panel to the blue line of the controller. 5. Connect the three-phase AC voltage input line of the controller to the three-phase voltage output line (green line) of the wind turbine. 6. After the entire connection is completed please wrap the connectors with waterproof tape to avoid water ingress. Indicator Light Conditions: 1. Battery capacity discharging indicator (Light on indicates the battery condition) 2. Solar charging indicator (Light on indicates charging) 3. Controller power-on indicator (Light on indicates the battery is connected properly) 4. Brake fault overcharge protection (Light on indicates condition) 5. Fan charging indicator (Light on indicates the fan is working) Package Contents: 1X Wind And Light for Hybrid Controller 1X Manual Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data. Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
