12V 13Pin European Standard Caravan Tow Bar Electrical Trailer Male Plug Plastic Socket

Package Included 1 x SocketSpecifications Model TM3008 for European cars Shape OblateMaterial PlasticColor BlackContact Material CopperSize Approx 6x7x5cm 2 36x2 76x1 97Features WaterproofNumber of Cores 13Number of Stitches 13Voltage Output 12VMain Function Connect trailer and power supply suitable for trailer lights displayApplications Commercial vehicles trailers RVs cars ships and so onWiring Configuration 13 Pin Lighting ConnectionsCable FunctionPin1 Yellow Wire Left Direction Indicator Pin2 Blue Wire Fog Light Pin3 White Wire Earth Return Pin4 Green Wire Right Direction Indicator Pin5 Brown Wire Right TailNo Plate Light Pin6 Red Wire Stop Light Pin7 Black Wire Left TailNo Plate Light Pin8 Pink Wire Reversing Light Pin9 Orange Wire 12V Permanent power from battery Pin10 Grey Wire 12V Ignition on Battery charging or Fridge Pin11 White Black Wire Earth for Terminal 10 Pin 12 White Blue Wire NOT usually used Pin 13 White Red Wire Earth for Terminal 9 More details
