110-240V 0~1300℃ REX-C100 Digital PID Temperature Controller Kit Alarm Function With Probe Relay

Package Included : 1 x REX-C100 PID Temperature Controller 1 x K Type Probe Sensor 1 x Max.40A SSR REX-C100 110-240V 0-1300 Degree Digital PID Temperature Controller Kit Features : 1.REX-C100 Temperature Controller 2.Measuring accuracy : ±0.5%FS 3.Cold-end compensation tolerance : ±2 can be modified by software in 0~50 4.Resolution : 14 bit 5.Sampling cycle : 0.5 Sec 6.Power : AC 110-240V 50/60HZ 7.Process value (PV) Setting value (SV) 8.Output, alarm and self-tuning can be indicated by : LED 9.PIN control (including ON/OFF, step-type PID and continuous PID) 10.Self-tuning control 11.Relay output : contact capacity 250V AC 3A (resistive load) 12.Alarm function output : 2 way 13.Proportional band (P) : 0~full range (ON/OFF control when set to 0) 14.Detective temperature range : 0 to 1300 15.Insulation resistance : >50M ohm(500V DC) 16.Insulation resistance : 1500V AC/min 17.Insulation resistance : Power Consumption < 10 VA 18.Service environment : 0~50 19.Environment with no corrosive gas 30~85% RH K Thermocouple Probe Cable 1.Length : 1M 2.Sensor diameter : 4.5mm 3.Temperature rang : 0 to 400(U can install to 1300 K Thermocouple Probe(not included) ) 4.Internal Insulation : Fiberglass 5.External Shielding : Insulated Shielding Max.40A SSR 1.Output Voltage Range : Standard Type 2.Output Current : 40A 3.Input Voltage : DC 3-32V 4.Output Voltage : 24-380V AC
