10pcs LM393 Single Tilt Sensor Module SCA60C Tilt Detection Sensor Module DC 5V for Smart Car

Manual Click here to openFeatures Working voltage DC 5V Main chip LM393 tilt sensing probe Analog voltage output of inclination signal 0 180 ° corresponds to 0 5 4 5V which can be collected by single chip microcomputer AD Two way tilt signal alarm output The low level indicator of the output effective signal is on The alarm of left and right tilt angle is adjustable from 0 90 ° to 90 180 ° the adjustment accuracy is ± 1 ° With mounting holes to facilitate fixed installation The tilt signal of the circuit board is TTL high and low level which can be directly connected to the IO port of the microcontroller Application Intelligent body balance detection teaching experiment demonstration product development etc Dimensions 3 1 x 2 1 x1 5 cm Interface Description 1 VCC external 5V voltage2 GND External GND3 DO1 left tilt TTL level output port directly connected to the IO port of the single chip microcomputer which is the threshold signal 4 DO1 right tilt TTL level output port directly connected to the IO port of the single chip microcomputer which is the threshold signal 5 VO is the voltage signal corresponding to the angle conversion and the output is an analog voltage value which can be connected to the input port of the single chip microcomputer with AD Package Included 10 x LM393 Single Tilt Sensor Module
