10pcs ESP8285 ESP-1 Serial Wireless WiFi Transmission Module Fully Compatible With ESP8266

Description: The WiFi module ESP-1 is manufactured by using a high-performance chip ESP8285. This small chip is encapsulated an enhanced Tensilica's L106 diamond series 32-bit kernel CPU with a SRAM. Thus, ESP8285 has the complete function Wi-Fi function; it not only can be applied independent but can be used as a slaver working with other host CPU. When ESP8285 is applied as a slave, it can start from the onboard Flash. The built-in high-speed buffer is not only benefiting improve the system performance but optimizing the store system. In addition, ESP8285 can be used as Wi-Fi adapter by SPI/SDIO or I2C/UART interface, when it is applied to other MCU design. More details, please visit this GitHub link to get the manual and tools, https://github.com/SmartArduino/SZDOITWiKi/wiki/ESP8285---ESP-1 Features: Ultra-small size; Support serial to WiFi; Wireless transparent transmission; Long distance transmission with ultra-low power; Support outboard antenna; Bearing high temperature to 125 compared to the 85 for ESP8266. Working temperature: -40-125 Module size:24.5mm*14mm; SOC characteristics: Built-in Tensilica L106 ultra-low power consumption 32-bit CPU, the main frequency can be 80MHz and 160MHz, also support RTOS; Built-in TCP/IP protocol stack; Built-in 1 channel 10-bit high precision ADC; The outside interfaces have HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO; The deep-sleep current is about 10uA, and the cut-off current is smaller than 5uA; Can be wake-up within 2 ms, and connect to transmit data package; the consumer power is smaller than 1.0mW (DTIM3) when at standby status; built-in 1M byte for SPI Flash. Wi-Fi characteristics: Support 802.11 b/g/n/e/i Support three modes: Station, SoftAP, and SoftAP+STA; Support Wi-Fi Direct(P2P); Support hardware acceleration for CCMP (CBC-MAC, computation mode) TKIP (MIC, RC4) WAPI(SMS4) WEP(RC4) CRC; P2P find, P2P GO mode/GC mode and P2P power management; WPA/PA2 PSK and WPS; Support 802.11 i security: pre-certification and TSN; Support 802.11n (2.4 GHz); 802.1h/RFC1042 frame encapsulation; Support seamless roam; Support AT remote updation and cloud OTA updation; Support SmartConfig function for Android and iOS device SmartConfig. Peripheral for Module: 1*UART; 1*En; MAX 4* GPIOs; Application: Serial Transparent transmission; WiFi probe; Smart power plug/Smart LED light; Mesh networks; Sensor networks; Wearable electronics; Securit ID label; Wireless location recognition; Wireless location system beacon; Industrial wireless control. Package included: 10 x ESP8285 ESP-1 Serial Wireless WiFi Transmission Module
