10Pcs Mos Field Effect Transistor Trigger Switch Driver Board Pwm Control Module
Description
Features: brand new and high quality Made of high-quality materials Dual MOS parallel active output lower internal resistance larger current powerful power 15A 400W at room temperature can meet the use of most equipment Wide voltage support PWM Easy to realize the control of high-power equipment Product parameters: Working voltage: DC 5V--36V; Trigger signal source: digital high and low level (DC3.3V--20V) can be connected to the microcontroller IO port PLC interface DC power supply can receive PWM signal signal frequency 0-20KHZ perfect support Output: DC DC 5V--36V continuous current 15A at room temperature power 400W! Auxiliary heat dissipation the maximum current can reach 30A. Application: The output can control high-power equipment motors bulbs LED strips DC motors pumps solenoid valves etc. can enter PWM control motor speed lamp brightness etc. Service life: unlimited switching Working temperature: -40-85 C Size: 3.4 * 1.7 * 1.2cm packing list: 10 *module Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data.
