10Pairs MC4 Connector Male And Female MC4 Solar Panel Connector 30A 1000V For PV Cable 2.5/4/6mm Solar Panel Connect

10Pairs MC4 Connector Male And Female MC4 Solar Panel Connector 30A 1000V For PV Cable 2.5/4/6mm Solar Panel Connect
Eachine1
sku: 1422036
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$10.88
Shipping from: China
   Description
Specification: Article number: MC4 Rated voltage 1000 V Rated impulse voltage: 1000 V Test voltage: 6 kV (50Hz) Suitable for cables: 10, 12, 14 AWG (2.5mm2 / 4mm2 / 6mm 2;) Rated current: 24 A-14 AWG (2.5mm 2;) 30A-12 and 10 AWG (4mm 2; and 6mm 2;) Protection class: IP67 Contact material: copper, silver plated Insulation material: PC / PA Operating temperature: -40 C + 90 C The security class: II Flame Class: UL94-V0 Contact resistance: 5m Insertion / withdrawal force: 50N / 50N Locking system: snap fit Package included: 10 x Male And Female MC4 Solar Panel Connector
