10A/20A/30A/40A/50A/60A 12/24V Auto PWM Digital Solar Charge Controller Battery Charger Solar Panel Regulator Dual USB L

Specifications Material ABSColor MulticolorsBatt Voltage 12V 24V auto adaptCurrent 10A 20A 30A 40A 50A 60AMax solar input 41VCharge drop 0 2VDischarge drop 0 25VEqualization 14 6VBulk 14 4VAcceptance 14 2V PWMFloat 13 8VCharge reconnect 13 0VDischarge Stop 10 8VDischarge reconnect 12 6VSelf consume 10mAVoltage of open light Solar panel 8V Light lights delay Voltage of close light Solar panel 8V Light off delay Temperature compensation N COperating Temperature 35 60℃Size L X W X H 13 3x7x3 5cm 5 24x2 76x1 38 appr Features ● Build in industrial micro controller● One key setting digital display● Fully 4 stage PWM charge management● Build in short circuit protection open circuit protection verse protection over load protection● Reverse current protection low heat production System Connection 1 Connect the battery to the charge regulator plus and minus it will show1if it detects 12V battery 2if it detects 24v battery 2 Connect the photovoltaic module to the regulator plus and minus 3 Connect the consumer to the charge regulator plus and minus The reverse order applies when deinstalling An improper sequence order can damage the controller Safety Instructions 1 Make sure your battery has enough voltage for the controller to recognize the battery type before first installation 2 The battery cable should be as short as possible to minimize loss 3 The regulator is only suitable for lead acid batteries OPEN AGM GELit is not suited for nicke
