100kg-3T Strain Gauge Pressure Sensor S Load Cell Electronic Scale Sensor Weighing Sensor

Feature: Range: 100kg, 200kg, 300kg, 500kg, 1T, 2T, 3T (optional) Overall accuracy: 0.03% F S Sensitivity: 2 0.1 mV / V Creep: 0.05% F S/30min Nonlinear: 0.03% F S Hysteresis error: 0.03% F S Repeatability error: 0.02% F S Zero temperature coefficient: 0.03% F S/10 Output temperature coefficient: 0.03% F S/10 Input impedance: 700 15 Output Impedance: 650 15 Insulation resistance: 5000 M For the bridge voltage: Recommended 10 VDC (standard signal 12V 24V) Operating temperature range:- 20 ~ +70 Safe overload: 150% F S Sealing Rating: IP67 Material: Alloy steel (40CrNiMo) Wiring Instructions: Power Positive: Red Power Negative: green Output Positive: Yellow Output Negative: white Package includes: 1 x Weighing Sensor
