100M USB VGA KVM Extender over Cat 5/5e/6 UTP Cable

Features
Extends local PC VGA/Keyboard/Mouse to remote side.
Superior video quality: up to 1920 x 1200.
Allow access to a computer from the remote console up to 100m distance.
Incorporating a compensation adjustment function at the remote unit for greater video quality.
Using single cable (cat 5, cat 5e, cat 6, utp), instead of bulky, expensive, standard cables, to provide a neater, more convenient, more reliable data transfer connection.
Supports (USB and PS/2 port) keyboard and mouse, it supports (VGA) port monitor.
Supports real time DDC communication.
Supports DOS, Windows, Linux, Unix system.
Easily add or remove computers connected to installation.
No external power supply needed for local unit.
Anti-lightning and anti-invasion protection: withstand air-discharge 15KV, contiguity-discharge 8KV.
Wall mountable.
Widely apply in the computer, monitor, security, multimedia teaching systems and so on.
Specifications
Input connector VGA, USB
Output connector VGA, 2-PS2
Local output HD15PIN (VGA)
Bandwidth 350MHZ
Input level range 0.5-2.0vp-p
Input level error less than 3Mv
Input impedance 75 ohm
Output impedance 75ohm
Echo ullage -30db @ 5MHx
Max DC compensation ± 5Mv-0
Video 1920 x 1200 @ 60Hz (at 30m), 1280 x 1024 @ 60Hz (at 100m)
SNR 60dB
Connector standard HDM 15, USB, Mini-DIN6, RJ45
Video standard VGA, SVGA, XGA, SXGA, UXGA, LCD
Cable standard CAT5, CAT5E, CAT 6 UTP
Transmitter size 9.5L x 7.5W x 2.5H cm
Receiver size 9.5L x 7.5W x 2.5H cm
Weight 740g
Package included 1 x KVM extender transmitter, 1 x KVM extender receiver, 2 x Power Adapter, 1 x USB cable, 1 x User Manual
Certification CE, FCC, RoHS
