100 Watt LED Pole Light fixture parking lot light outdoor shoebox light dlc et

This 100WATT LED Pole Light provides an excellet illunative solutions to parking areas,airports, roadways. campuses and streetcapes.
It achieves a high luminous efficacy of 86 lm/W by utilizing high quality Cree LED diodes. Three mounting available for different applications: Arm mount, Slipfitter mount, Trunnnion mount. With effective thernal management corrision-resistant, and die-cast aluminum enclosure with an architechtural brown finish. The LED light provides glare free, uniform illumination while providing a safe and comfortable visual experience.
Installation
a. Cut off the power and make sure the wall can be burden the weight of lamp before install the lamp.
b. Put hole connect with stree light pole and make connection of red with L, blue with N, yellow with earth line.
c. Adjust beam angle by rotating the LED stree arm.
d. Turn it on when adjustable properly.
Note
a. Make sure the lamp in the area with aggressive gas.
b. Do not use the lamp in the area with anything which is harm for heat dissipation.
c. Be careful and connect the ground line well.
Application
It is widely used in parking lot, wall lighting area, street lighting, etc.
Replaces standard 200-300watt metal halide, high pressure sodium. Quartz or other HID units
60% to 80% of existing energy saving
Slip-fitter work on bracket 50-60mm(1.9" to 2.36")
Rotable arm with 180 degree rotable
Aluminum heatsink fin structure with light weight and favourable cooling system.
LUMINOUS SMD3030 chips high brightness
Flexible and convenient installation wildely used square, park, street, highway landscape road lighting
For parking lot light 100/150/200/300/400w are optional
Not include the long bracket. Only light
Wattage: 100W
Voltage: AC110V
LED quantity: 48pcs
Lumen: 11000LM
CCT: 4800-5300K
CRI: ≥70
Driver: Meanwell
Beam angle: 90x120degree
Body finished: Black
Certification: ROHS,ETL,DLC,CE
Storage environment: -104℉ ~113℉(–40°C ~ 50°C)
Warranty: 5 years
1 X 100watt LED Parking Lot Light
