10.1 inch 2K Resolution 2560x1600(16:10) Independent Display Monitor TFT Screen With Driver Board&Keyboard Module For Raspberry Pi/Orange Pi/PC/Tablet PC

Overview: This Model LR1012K01 Display is a color active matrix TFT (Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 10.1" contains 2560 x 1600(16:10) and can display up to 16,194,277 colors. 6 O'clock direction is the optimum viewing angle. Features: High contrast ratio, Ultra wide viewing angle 2560 x 1600(16:10) WQ resolution, 16,194,277 colors Low power consumption LED Back Light with internal LED Driver With OBD menu, support multi languge menu. Fast Response eDP(V1.1) Input Interface LVDS Interface 2CH Green product (BFR/CFR/PVC Free) Signal input: HDMI input or VGA & Audio Input(VGA only support Image signal) Notice: The Raspberry pi 3B+ only support the maximum resolution 1920 x 1080, not 2560x1600. Power Supply: Wide voltage input, DC 7V-12V, 2A Applications: - Tablet PC - Desktop Computer - Raspberry Pi 3 Model B+ 3B 2B B+ - Orange Pi Series - Beaglebone Black Series Specification: - Display area: 216.576mm(H) X 135.36mm(V) (10.05"diagonal) - Driver element: a-Si TFT active matrix - Display colors: 16,194,277(6bit+FRC) - Resolution: 2560 * 1600 (16:10) - Pixel arrangement: RGBW vertical stripe - Pixel pitch: 0.0423mm(H) x 0.0846mm(V) (TYP.) - Display Mode: Normally black (PLS mode) - Surface treatment: 2H (Glare) More info. can refer to WIKI Package Included: 1 x 10.1 Inch Full HD Screen 1 x Drive Board 1 x Keyboard Board
