10 Pcs TTC Tiger Switch Standard Edition Keyboard Switch 45g Bottom Out Force 55g 5 Pins Lubed 25.5mm Long Spring Trigge

Specification G series TTC Tiger keyboard switch standard version Type Linear Total travel 3 7 0 4mmPre travel 1 08 0 6 0 2mmOperating force 45±5gfContact Double gold contactDurability 100 MillionFeatures 1 5 pins the terminals with silver plated anti corrosion coating can greatly improve the life of the pins and the dispensing process can prevent the penetration of rosin and corrosive gases during wave soldering 2 Trigger 45g and bottom out force 55g The initial pressure of the shaft body is increased to prevent false touch operation The shaft center stroke pressure is even the hand feel is more strong the rebound is faster and the bottom end of the spring is greased which can effectively eliminate the spring sound 3 25 5mm long gold plated spring4 The stem is integrrated lengthened conduction 1 08mm bottoming stroke 3 7mm Stem is light lube smooth enoug 5 The upper cover is translucent with TTC on the front The standard version of TTC tiger switch adopts orange red stem black translucent upper cover and orange red switch station 6 The life of the tiger shaft is as high as 100 million times The shell fragment and terminals are silver plated for better conductivity and higher stability The gold plated contacts pass through the silver plated shell fragment to be riveted firmly and reliably the unique structure and noise reduction technology The sound of pressing and rebounding is more mellow and full in the case of the sound absorbing pad Packa
