10-50V 100A 3000W PWM Programable Reversible DC Motor Speed Controller

Feature Larger current max current up to 100A continuous operating current recommend 60A Reversing control motor dual relay control can withstand higher current Programmable to meet subsequent extensions Specification 1 Operating voltage DC 10V DC 50V2 Control power 0 01 3000W maximum rated current of 60A different operating voltages corresponding to different control power as follows Operating voltage 12V 12V 100A 1200WOperating voltage 24V 24V 100A 2400WOperating voltage 30V 30V 100A 3000W3 Quiescent current 0 04A operating voltage DC10V to DC30V quiescent current will not exceed 40ma 4 PWM duty cycle 0 100 5 PWM frequency 15khz6 Operating temperature 20℃ 40℃ ambient temperature of minus 20 degrees to 40 degrees above zero The governor of the industrial grade quality can be less than zero stable work environment general commercial grade quality of governor in It is not stable work in sub zero temperatures 7 Circuit board dimensions 145 x 80 x 40mm 5 7 x 3 1 x 1 6 not including adjustment portion potentiometer Main Purpose 1 Various types of general purpose DC brush motor speed2 Various types of vehicles with motor speed automotive cooling fan speed auto fan speed auto wiper motor speed automotive air conditioning fan speed 3 The production line belt speed pipeline exhaust fan speed treadmill speed multiple computers in parallel fan speed control electronic fan speed control 4 Various types of DC lamp dimmer various
