1-8000MHz AD8318 RF Logarithmic Detector 70dB RSSI Measurement Power Meter

Product Usage The RF detector is made of ADIs AD8318 chip the design of the power supply voltage regulator circuit such that the detection accuracy tends to official data the operating frequency range is 1 8000MHz can detect 65 to 5dBm RF signal and with DC voltage output the detected signal strength in dBm logarithmic detection so the RF signal is converted into a DC voltage output RF signal corresponding to the amplitude or power of the output voltage You can do signal strength indicator RSSI spectrum analyzer gain control Technical Specifications 1 The operating frequency 1 8000MHz2 Dynamic Range 65dBm to 5dBm3 The detection slope 25 mV dB TPY 4 The detection output voltage range 0 5 2 1V5 Power supply voltage 7 15VDC containing the power regulator circuit 6 The input impedance 50 ohms7 RF interface standard SMA femalePackage included 1 x 1 8000MHz AD8318 RF Logarithmic Detector
