08350 Pocket Hole Jig 3 in 1 Drilling Locator Guide Dowel Guide Jig Woodworking Positioner Tenon Hole Puncher

Description 3 in 1 Drilling Locator Guide Dowel Guide Jig Woodworking Carpentry Positioner Tenon Hole Puncher Specification Name 08350 three in one puncherMain Body Material Aluminum alloy 6061 surface anodizing treatment Drilling sleeve material die steelFunction woodworking three in one positioning punch Type A Clamp 10 45mm thickness boardThreaded rod drill sleeve adjustment range 5 30MMEccentric wheel drill sleeve adjustment range 28 45MM Type B Clamp 10 70mm thickness boardThreaded rod drill sleeve adjustment range 5 50MMEccentric wheel drill sleeve adjustment range 25 60MM Drill sleeve adjustment size 40MM connecting rod eccentric wheel drill sleeve adjustment scale 33MM Calculation method connecting rod length 7MM Threaded Pole drill set adjustment scale is half the board thickness eg 18mm board thickness adjustment scale 9mm Features The main purpose To achieve a variety of wood products connection Technical treatment heat treatment and hardening good abrasion resistance long service life Instructions 1 The puncher is fixed on the board it is recommended to be 30mm from the edge 2 Adjust the distance between the limit ring and the drill sleeve to determine the depth of the hole3 Drill the threaded rod hole and insert the round raft4 The puncher is attached to the round raft and then clamps the board5 Start drilling6 Lock the wood board when drilling the eccentric wheel hole please ensure that the drill bit is perpendicular to the drill sle
