Материнская плата PRIME Q370M-C, 90MB0W70-M0EAYM

Процессор: Intel® for 8th Generation Core™ Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors *Refer to www.asus.com for CPU support listSupports Intel® 14 nm CPUSupports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
Оперативная память: 4 x DIMM, Max. 64Гб, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory *Hyper DIMM support is subject to the physical characteristics of individual CPUs. Supports Intel® Extreme Memory Profile (XMP)*Refer to www.asus.com or this user manual for the Memory QVL (Qualified Vendors Lidts).* The maximum memory frequency supported varies by processor.** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
Хранилище данных: Intel® Q370 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (x4 PCIE mode)6 x SATA 6Gb/s port(s)Support Raid 0, 1, 5, 10Intel® Optane™ Memory Ready
Аксессуары: User's manualI/O Shield2 x SATA 6Gb/s cable(s)3 x M.2 Screw Package1 x Supporting DVD
Примечание: *1: Use a chassis with HD audio module in the front panel to support an 8-channel audio output.*2: Use with amplified speaker is suggested.
Аудио: Realtek® ALC887 8-Channel High Definition Audio CODEC- Supports : Jack-detection, Front Panel Jack-retasking
Слоты расширения: 1 x PCIe 3.0/2.0 x16 2 x PCIe 3.0/2.0 x1 1 x PCI
Локальная сеть: Intel® I219LM, 1 x Gigabit LAN Controller(s)
Порты USB: Intel® Q370 Chipset : 4 x USB 3.1 Gen 2 port(s) (4 at back panel, , Type-A, 0 at mid-board)Intel® Q370 Chipset : 4 x USB 3.1 Gen 1 port(s) (2 at mid-board)Intel® Q370 Chipset : 4 x USB 2.0 port(s) (2 at back panel, , Type-A, 2 at mid-board)
Эксклюзивные особенности: TPM IC OnboardBespoke Motherboard Design & Business Focused Features :- ASUS Self Recovering BIOS: Automatically recover BIOS update once crash happen- ASUS Event Log: Record activities of system and provides information in BIOS- ASUS Commercial BIOS kit: Speed up BIOS update solutionby partial BIOS design- Anti-Moisture: Against moisture and corrosion — prolonging the life of your motherboard- 24/7 Reliability: Tested under temperature up to 45°C and humidity up to 80% to ensure handle diverse environmentEasy Assembly Design:- Fixed-position&Color-coded Connectors: Enable easy identification and cable-matching, speeding up the production line- Box Headers: USB headers are box style, enabling fast connector installation and preventing pin damageDigi+VRM
Поддержка операционной системы: Windows® 10
Разъемы на задней панели: 1 x PS/2 keyboard (purple)1 x PS/2 mouse (green)1 x D-Sub2 x DisplayPort1 x HDMI1 x LAN (RJ45) port(s)4 x USB 3.1 Gen 2 Type-A2 x USB 2.0 3 x Audio jack(s)
Разъeмы на плате: 1 x MONO out header *22 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)1 x LPT header2 x COM port(s) connector(s)6 x SATA 6Gb/s connector(s)1 x CPU Fan connector(s) (1 x 4 -pin)2 x Chassis Fan connector(s) (2 x 4 -pin)1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x Internal speaker connector(s)1 x System panel(s) 1 x Chassis Intrusion connector(s)1 x M.2 Socket 1 with E key, type 2230 for Wi-Fi/BT devices support or PCIE/USB mode1 x LPC Debug header
Администрированиe: WOL, PXE
Графика: Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI/RGB/DisplayPort ports - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz Maximum shared memory of 1024 MB (for iGPU exclusively)Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™Supports up to 3 displays simultaneously
Форм-фактор: uATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
Чипсет: Intel® Q370
BIOS: 192Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS smart recovering BIOS, ASUS Event log, ASUS Commercial Kit
Диск с драйверами: Watch dog timer, Drivers
Страна производства: Китай
