Материнская плата Asus ITX-220 встроенный процессор Celeron 220, s478

Материнская плата Asus ITX-220 встроенный процессор Celeron 220, s478
Характеристики:
CPU
Intel® Celeron 220
CPU Fan
- Dimension of Fan: 40*40*10ｍｍ
- Rated Speed: 6000±10% R.P.M.
- Voltage(V): DC 12V
- Maximum Air Flow: 5.57CFM
- Noise: 25.3dBA (Max. 27.5 dBA)
Chipset
Intel® 945GC /ICH7
Front Side Bus
533 MHz
Memory
2 x DIMM, Max. 4 GB, DDR2 533 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
* Refer to www.asus.com or user manual for Memory QVL (Qualified Vendor List)
Expansion Slots
1 x PCI
VGA
Integrated Intel Graphics Media Accelerator 950
D-sub Max. resolution: 2048x1536x32Bppx75Hz
Maximum shared memory of 224 MB
Storage
Southbridge
2 xSATA 3 Gb/s ports
LAN
Realtek PCIE Gb LAN
Audio
VIA VT1705 6 -Channel High-Definition Audio CODEC
USB
6 USB 2.0 ports (2 ports at mid-board, 4 ports at back panel)
Special Features
ASUS MyLogo 2
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
Back Panel I/O Ports
1 x D-Sub
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN(RJ45) port
4 x USB 2.0/1.1
1 x COM port
6 -Channel Audio I/O
Internal I/O Connectors
1 x USB connectors supports additional 2 USB ports
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Speaker connector
1 x Chassis Intrusion connector
1 x Front Panel connector
1 x High Definition front panel audio connector
1 x 24-pin EPS 12V Power connector
1 x 4-pin ATX 12V Power connector
1 x TPM header (optional)
BIOS
8 Mb Flash ROM
AMI BIOS, PnP, DMI v2.0, Wfm2.0, SM BIOS 2.5, ACPI v2.0a
Accessories
User's manual
1 x I/O Shield
1 x SATA cable
Support Disc
Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS Update
English User's Manual
Form Factor
Mini ITX Form Factor
6.75 inch x 6.75 inch ( 17.1 cm x 17.1 cm )
