Материнская плата ASUS TUF GAMING X570-PRO (WI-FI), TUF GAMING X570-PRO (WI-FI)

Процессор: AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series Desktop Processors/3rd, 2nd and 1st Gen AMD Ryzen™ with Radeon™ Graphics Processors * Refer to www.asus.com for CPU support list* Due to CPU limitation, CPU cores supported varies by processors.
Хранилище данных: AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors : 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices supportAMD RyzenTM 4000 G-Series / 3000 G-Series / 2000 Series / 2000 G-Series Processors : 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices supportAMD X570 chipset : 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support8 x SATA 6Gb/s port(s)Support Raid 0, 1, 10
Операционная система: Windows® 10 64-bit
Аксессуары: User´s manualI/O Shield2 x SATA 6Gb/s cable(s)1 x M.2 Screw Package1 x Supporting DVD1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)1 x TUF GAMING Sticker1 x TUF Certification card(s)1 x M.2 Rubber Package(s)
Аудио: Realtek® ALC S1200A 8-Channel High Definition Audio CODEC Audio Feature :- Exclusive DTS Custom for GAMING Headsets.- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity- Audio Cover: Effective shielding preserves the integrity of audio signals to ensure best quality.
Поддержка технологий Multi-GPU: 3rd and 2nd Gen AMD Ryzen™/3rd, 2nd and 1st Gen AMD Ryzen™ with Radeon™ Graphics ProcessorsSupports AMD 2-Way CrossFireX™ Technology
Слоты расширения: AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors1 x PCIe 4.0 x16 (x16 mode) AMD RyzenTM 4000 G-Series / 2000 Series Processors1 x PCIe 3.0 x16 (x16 mode) AMD RyzenTM 3000 G-Series / 2000 G-Series Processors1 x PCIe 3.0/2.0 x16 (x8 mode) AMD X570 chipset1 x PCIe 4.0 x16 (max at x4 mode) 2 x PCIe 4.0 x1
Порты USB: Rear USB Port ( Total 7 ) 3 x USB 3.2 Gen 2 port(s)(2 x Type-A +1 x Type-C)4 x USB 3.2 Gen 1 port(s)(4 x Type-A)Front USB Port ( Total 7 ) 1 x USB 3.2 Gen 2 front panel connector port(s)(1 x Type-C)2 x USB 3.1 Gen 1 port(s)(2 x Type-A)4 x USB 2.0 port(s)(4 x Type-A)
Bluetooth: Bluetooth v5.1**BT 5.1 function will be ready in Windows 10 build 19041 or later.
Графика: Integrated Graphics in AMD Ryzen™ 4000 G-Series/ 3000 G-Series/ 2000 G-Series Desktop Processors Multi-VGA output support : HDMI/DisplayPort ports - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz - Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz
Беспроводная передача данных: Intel® Wi-Fi 6 AX2002x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMOSupports up to 2.4Gbps max data rateSupports dual band frequency 2.4/5 GHzSupports channel bandwidth: HT20/HT40/HT80/HT160Supports PCIe interface
Форм-фактор: ATX Form Factor 12.0 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Внутренние разъемы: 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) 1 x AIO_PUMP connector 2 x Aura RGB Strip Header(s)1 x Addressable Gen 2 header(s)1 x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin, Type-C)2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)1 x SPI TPM header8 x SATA 6Gb/s connector(s)1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)1 x 4-pin ATX 12V Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x System panel(s) 1 x Clear CMOS jumper(s)1 x COM port header1 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports
Чипсет: AMD X570
LAN: Intel® I225-V 2.5Gb EthernetASUS Turbo LAN UtilityTUF LANGuard
BIOS: 256Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, F4 AURA ON/OFF, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information
Память: 4 x DIMM, Max. 128GB, DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory Dual Channel Memory Architecture * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).* The maximum memory frequency supported varies by processor.
Специальные функции: ASUS TUF PROTECTION- ASUS SafeSlot: Protect your graphics card Investment- ASUS ESD Guard: Enhanced ESD protection- ASUS Overvoltage Protection: World-class circuit-protecting power design- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!- ASUS DIGI+ VRM: Precision control for stable power- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!AURA :- Aura Lighting Control- Aura RGB Strip Headers- Addressable Gen 2 HeaderASUS Exclusive Features :- AI Suite 3- Ai Charger ASUS Quiet Thermal Solution :- Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan, PCH and M.2 Heatsink- ASUS Fan Xpert 4ASUS EZ DIY :- ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS USB BIOS FlashBack™- ASUS UEFI BIOS EZ ModeASUS Q-Design :- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)- ASUS Q-Slot- ASUS Q-DIMM DIY Friendly Design- Procool- SafeSlot- Digi+ VRM- Highly Durable components- ESD Guards
Входы/выходы на задней панели: 1 x PS/2 keyboard/mouse combo port(s)1 x DisplayPort1 x HDMI1 x LAN (RJ45) port(s)1 x Optical S/PDIF out5 x Audio jack(s)1 x BIOS FlashBack™ Button(s)1 x ASUS Wi-Fi Module4 x USB 3.2 Gen 1 (up to 5Gbps) ports 3 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A + USB Type-CTM)
Управляемость: WOL by PME, PXE
Особенности ПО: ASUS Exclusive SoftwareArmoury Crate- Aura Sync- AI Noise-Canceling MicrophoneAI Suite 3- Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert 4 EZ updateASUS CPU-ZAI Charger ASUS Turbo LANDAEMON ToolsDTS Custom for GAMING HeadsetsNorton Anti-virus software (Free Trial for 60 days) WinRARUEFI BIOSASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode
Страна производства: Китай
