Материнская плата ASUS ROG STRIX B360-F GAMING, ROG STRIX B360-F GAMING

Процессор: Intel® Socket 1151 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supports Intel® 14 nm CPUSupports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.* Refer to www.asus.com for CPU support list
Хранилище данных: Intel® B360 Chipset : 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)*41 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)6 x SATA 6Gb/s port(s)Intel® Rapid Storage Technology supportsIntel® Optane™ Memory Ready *5
Операционная система: Windows® 10 64-bit
Аксессуары: User's manual4 x SATA 6Gb/s cable(s)1 x M.2 Screw Package1 x Supporting DVD1 x CABLE TIE BLACK1 x ROG Strix stickers1 x ROG Door Hanger(s)1 x Extension Cable for RGB strips (80 cm)1 x 3D printing mount package
Аудио: ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A - Dual Headphone Amplifiers- Impedance sense for front and rear headphone outputs- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input- SupremeFX Shielding Technology- Supports up to 32-Bit/192kHz playback *6Audio Feature :- Optical S/PDIF out port(s) at back panel- Sonic Radar III- Sonic Studio III + Sonic Studio Link
Поддержка технологий Multi-GPU: Supports AMD 2-Way CrossFireX Technology
Слоты расширения: 8th Generation Intel® Core™ Processor1 x PCIe 3.0/2.0 x16 (x16 mode) Intel® B360 Chipset1 x PCIe 3.0/2.0 x16 (x4 mode) *24 x PCIe 3.0/2.0 x1 *3
Порты USB: Intel® B360 Chipset : 1 x USB 3.1 Gen 2 port(s) (1 at back panel, black, USB Type-CTM, Support 3A power output)Intel® B360 Chipset : 2 x USB 3.1 Gen 2 port(s) (2 at back panel, red, Type-A, Support 3A power output)Intel® B360 Chipset : 2 x USB 3.1 Gen 1 port(s) (2 at mid-board)Intel® B360 Chipset : 6 x USB 2.0 port(s) (4 at back panel, black, 2 at mid-board)
Графика: Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI/DVI-D/DisplayPort ports - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz *1
Дополнительно: *1 DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays.*2 The PCIEX16_2 slot shares bandwidth with PCIEX1_1 and PCIEX1_2 slots. When PCIEX1_1 and PCIEX1_2 slots are occupied, PCIEX16_2 slot runs at x2 mode. *3 The M.2_1 socket shares bandwidth with PCIEX1_4 *4 The M.2_1 socket shares bandwidth with SATA6G_2 port when using M.2 SATA mode device. Adjust BIOS settings to use X2 mode (PCIE only). The M.2_1 socket shares bandwidth with PCIEX1_4 *5 The M.2_2 socket supports Intel® Optane™ Technology. Intel® Optane™ Technology only supported when using 8th Generation Intel® Processors. Before using Intel® Optane™ memory modules, ensure that you have updated your motherboard drivers and BIOS to the latest version from ASUS support website.*6 Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
Форм-фактор: ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Внутренние разъемы: 1 x AAFP connector1 x Aura RGB Strip Header(s)1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)6 x SATA 6Gb/s connector(s)1 x M.2_FAN connector1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 2 x Chassis Fan connector(s) 1 x AIO_PUMP connector 1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)1 x System panel(s) 1 x 5-pin EXT_FAN(Extension Fan) connector1 x Thermal sensor connector(s)1 x Clear CMOS jumper(s)1 x 14-1 pin TPM connector1 x COM port header2 x 3D Mount screw port(s)
Чипсет: Intel® B360
LAN: Intel® I219V, 1 x Gigabit LAN Controller(s), Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY)Anti-surge LANGuardROG GameFirst Technology
BIOS: 1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, Secure Erase, User Profile, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, , F4 AURA ON/OFF and F9 Search
Память: 4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP)* Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
Специальные функции: Fan Xpert4- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling controlGamer's Guardian:- ESD Guards on LAN, Audio, KBMS and USB3.1/3.0/2.0 ports - DRAM Overcurrent Protection- Stainless Steel Back I/O- Highly Durable Components- SafeSlotAURA :- Aura Lighting Control- Aura RGB Strip Headers- Aura Lighting Effects Synchronization with compatible ASUS ROG devicesASUS Exclusive Features :- AI Suite 3- Ai Charger ASUS EZ DIY :- ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 ASUS Q-Design :- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)- ASUS Q-Slot- ASUS Q-DIMM Gaming Aesthetics :- 3D printing friendly- AURA-RGB LightingDigi+VRM
Входы/выходы на задней панели: 1 x PS/2 keyboard/mouse combo port(s)1 x DVI-D1 x DisplayPort1 x HDMI1 x LAN (RJ45) port(s)1 x USB 3.1 Gen 2 (black)USB Type-CTM, 2 x USB 3.1 Gen 2 (red)Type-A4 x USB 2.0 1 x Optical S/PDIF out5 x Audio jack(s)
Управляемость: WOL, WOR, PXE
ROG Exclusive Features: ROG RAMCache IIROG CPU-ZROG CloneDrivePre-mounted I/O ShieldOverwolfGameFirst IVROG Aura- Aura Lighting Control- Aura RGB Strip Headers
Страна производства: Китай
