Материнская плата ASUS PRIME Z390-P, PRIME Z390-P

Процессор: Intel® Socket 1151 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supports Intel® 14 nm CPUSupports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.* Refer to www.asus.com for CPU support list
Хранилище данных: Intel® Z390 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*11 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)4 x SATA 6Gb/s port(s)Support Raid 0, 1, 5, 10Intel® Rapid Storage Technology supportsIntel® Optane™ Memory Ready Intel® CPU with Intel® Rapid Storage Technology support (RAID 0 & RAID 1)PCIEX16_1 slot supports up to 3 Intel® PCIe NVME SSDs via a Hyper M.2 X16 series Card
Операционная система: Windows® 10 64-bit
Аксессуары: User's manualI/O Shield2 x SATA 6Gb/s cable(s)2 x M.2 Screw Package1 x SCD
Аудио: Realtek® ALC887 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Front Panel Jack-retaskingAudio Feature :- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity* Choose the chassis with HD audio module in front panel to support 8-channel audio output.
Поддержка технологий Multi-GPU: Supports AMD CrossFireX™ Technology
Слоты расширения: 1 x PCIe 3.0/2.0 x16 (x16 or x8+x4+x4) 1 x PCIe 3.0/2.0 x16 (max at x4 mode) 4 x PCIe 3.0/2.0 x1 1 x M.2 Socket (Key E), supports type 2230 Wi-Fi/BT and Intel® CNVi (Integrated Wi-Fi/BT) module**For 3 SSD on CPU support, install a Hyper M.2 X16 card (sold separately) into the PCIeX16_1 slot, enable this card under BIOS settings.* The Wi-Fi/BT module is purchased separately
Порты USB: Intel® Z390 Chipset : 2 x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A)Intel® Z390 Chipset : 8 x USB 3.1 Gen 1 port(s) (4 at back panel, , Type-A, 4 at mid-board)Intel® Z390 Chipset : 3 x USB 2.0/1.1 port(s)
Графика: Integrated Graphics Processor- Intel® UHD Graphics support Multi-VGA output support : HDMI/DisplayPort ports - Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays
Дополнительно: *1.When a device in SATA mode is installed on the M.2_1 socket, SATA6G_2 port cannot be used.
Форм-фактор: ATX Form Factor 12.0 inch x 9.2 inch ( 30.5 cm x 23.4 cm )
Внутренние разъемы: 1 x Lighting Control RGB Strip Header(s)2 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s) 1 x USB 2.0 1-port connector(s) support(s) additional 1 USB 2.0 port(s)1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)1 x M.2 Socket 1 with E key, type 2230 Wi-Fi/BT device support or Intel® CNVi (Integrated Wi-Fi/BT) module1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)1 x COM port(s) connector(s)4 x SATA 6Gb/s connector(s)1 x CPU Fan connector(s) 2 x Chassis Fan connector(s) 1 x AIO_PUMP connector 1 x S/PDIF out header(s)1 x 8-pin EATX 12 V Power connector1 x 24-pin EATX Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x MemOK! II switch(es)1 x Clear CMOS jumper(s)1 x System panel connector
Администрирование: WOL by PME, PXE
Чипсет: Intel® Z390
LAN: Realtek® RTL8111H, support LANGuard
BIOS: 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information
Диск с драйверами: DriversASUS UtilitiesASUS EZ Update Anti-virus software (OEM version)
Память: 4 x DIMM, Max. 128GB, DDR4 4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP)* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).* The maximum memory frequency supported varies by processor.
Специальные функции: Fan Xpert4- Advanced fan and liquid controls for ultimate cooling and quietnessASUS 5X Protection III :- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!- ASUS Overvoltage Protection: World-class circuit-protecting power design- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!- ASUS DIGI+ VRM: Premium components provide better power efficiencyASUS Optimem II：- Optimem (Improved DDR4 stability)ASUS EPU :- EPU ASUS Exclusive Features :- AI Suite 3- Ai Charger ASUS Quiet Thermal Solution :- Stylish Fanless Design Heat-sink solution & MOS Heatsink - ASUS Fan Xpert 4ASUS EZ DIY :- ASUS O.C. Tuner- ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 ASUS Q-Design :- ASUS Q-Slot- ASUS Q-DIMM Overclocking Protection :- ASUS C.P.R.(CPU Parameter Recall)M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)MemOK! II- Enhance memory compatibility. More smart and convenient. Keep high performance. (Shorten the PC starting time)Q-Installer- Auto download driver and software. Friendly for first PC builder.
Входы/выходы на задней панели: 1 x PS/2 keyboard (purple)1 x PS/2 mouse (green)1 x DisplayPort1 x HDMI1 x LAN (RJ45) port(s)2 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1 Type-A 3 x 8-channel Audio I/O
Страна производства: Китай
