Материнская плата ASUS PRIME H410M-K, 90MB13I0-M0EAY0

Процессор: Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors *Supports Intel® 14 nm CPUSupports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0*** Refer to www.asus.com for CPU support list**Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Хранилище данных: Total supports 4x SATA 6Gb/s portsIntel® H410 Chipset : 4 x SATA 6Gb/s port(s)
Операционная система: Windows® 10 64-bit
Аксессуары: I/O Shield2 x SATA 6Gb/s cable(s)1 x Supporting DVDUser manual
Аудио: Realtek® ALC887 7.1-Channel High Definition Audio CODEC *- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playbackAudio Feature :- Audio Shielding- Dedicated audio PCB layers* Choose the chassis with HD audio module in front panel to support 8-channel audio output.
Слоты расширения: Intel® 10th Gen Processors 1 x PCIe 3.0 x16 (x16 mode) Intel® H410 Chipset2 x PCIe 3.0 x1
Порты USB: Rear USB Port ( Total 6 ) 2 x USB 3.2 Gen 1 port(s)(2 x Type-A)4 x USB 2.0 port(s)(2 x Type-A)Front USB Port ( Total 4 ) 2 x USB 3.2 Gen 1 port(s)2 x USB 2.0 port(s)
Графика: Integrated Graphics Processor 1 x DVI-D 1 x D-Sub *Graphics specifications may vary between CPU types.
Форм-фактор: mATX Form Factor 8.9 inch x 7.9 inch ( 22.6 cm x 20.3 cm )
Внутренние разъемы: 1 x CPU Fan connector(s) 1 x Chassis Fan connector(s) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)4 x SATA 6Gb/s connector(s)1 x S/PDIF out header(s)1 x 24-pin EATX Power connector(s)1 x 8-pin EATX 12V Power connectors1 x Front panel audio connector(s) (AAFP)1 x Clear CMOS jumper(s)1 x System panel connector1 x COM port header1 x Speaker connector
Чипсет: Intel® H410
LAN: Realtek® RTL8111H
BIOS: 128 Mb Flash ROM, UEFI AMI BIOS
Память: 2 x DIMM, Max. 64GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP)OptiMem* 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133 natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Входы/выходы на задней панели: 1 x PS/2 keyboard (purple)1 x PS/2 mouse (green)1 x DVI-D1 x D-Sub1 x LAN (RJ45) port(s)2 x USB 3.2 Gen 1 Type-A 4 x USB 2.0 3 x Audio jack(s)
Управляемость: WOL by PME, PXE
Особенности ПО: ASUS Exclusive SoftwareArmoury CrateAI Suite 3- Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert- EZ updateASUS CPU-ZAI Charger DAEMON ToolsNorton Anti-virus software (Free Trial for 60 days)WinRARUEFI BIOSASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode
Особенности ПО ASUS: ASUS 5X PROTECTION III- ASUS DIGI+ VRM- ASUS LANGuard- ASUS Overvoltage Protection- ASUS SafeSlot Core- ASUS Stainless-Steel Back I/OASUS Q-Design - ASUS Q-DIMM- ASUS Q-SlotASUS Thermal Solution- Aluminum heatsink design
Страна производства: Китай
