X720 UPS HAT (18650 Power)+Safe Shutdown + Wake on Lan + RTC Power Management Expansion Board for Raspberry Pi 3 B+/3B
1: UPS HAT (max. 3A output) 2. Safe shutdown 3. Wake on lan (WOL) 4. Real Time Clock(RTC) Overview: The X720 is a multifunctional expansion board for all current models of the Raspberry Pi using a 40 pin header.It provides intelligent and safe power management, remote power on/wake on lan, safe shutdown and full poweroff through software, an advanced uninterruptible power supply, second 10/100M fast ethernet, and a real- time clock. The X720 reserves the 40-pin header that can be stacked with other Raspberry Pi accessory boards for enhanced applications. The X720 can also be used with the X820 (2.5" HDD/SSD Shield) and X850 (Msata SSD shield) for safe data backup. Features: Smart Uninterruptible Power Supply (UPS) Provides continuous operations for up to 10hours (depending on battery type used) 5.1V 3000mA Power Backup for even the most demanding Pi 3 set ups 18650 dual Cells Lithium Ion Holder Can work with single or dual 18650 Lithium Ion battery Integrated battery protection circuit Integrated over current protection and over voltage protection Intergrated Maxim's fuel-gauge systems (Reading battery voltage and precentage via i2c) Intelligent automatic charging and discharging Automatic safe shutdown when battery low (voltage 8seconds to force shutdown Supports safe shutdown and full poweroff through software On-board LED shows the status of power on, reboot and shutdown Integrated second 10/100M fast ethernet Supports remote power on/wake on lan via Link-change, Magic packet, MS wakeup frame On-board LED shows the status of power on/wakeup packet indication Integrated Hardware Real Time Clock (RTC) with Battery Back-Up Keeps track of the time while the Raspberry Pi is switched off Allows the Raspberry Pi to retrieve the current date and time when it is switched back on Uses the most precise DS3231 RTC real time clock Uses the 18650 battery to maintain the date and time - no additioanl battery required Reserved 40-pin stackable Header for Add-On Boards Powers the Raspberry Pi via the 40-pin header - no additional cabling required Works with all current models of the Raspberry Pi using a 40 pin header Power management and second ethernet can still work without battery On-board DC jack (5.5*2.5mm) and micro-USB socket convenient for power input On-board connector allowing to connect external power switch and DIY your perfect case Mounting holes and standoffs provide mechanical stability of the Raspberry Pi and X720 assembly Specification: Power supply: 5Vdc +/-5% via on board micro-USB socket Ports & Connectors: DC jack - 5.5x2.5mm x1 Micro-USB socket x1 Power output connector - XH2.54 2-pin PCB Size: 85mm x 63mm More info. can refer to WIKI [Packing List] 1 x X720 Expansion Board 1 x Installation Screws Pack 1 x 2Pin Cable 1 x USB Cable (Length: 10cm/3.93inch, only need it when you use WOL function)
