UNI-T Digital Multimeter UT61A UT61B UT61C UT61D UT61E AC DC Volt Ampere Ohm meter Capacitance Frequency Diode Duty cycle tester
Technical Details
| AC Current: | 200uA/2200uA/22mA/220mA/2.2A/10A ±(0.8%+10) |
| AC Voltage: | 220mV/2.2V/22V/220V/1000V ±(0.8%+10) |
| Auto Range: | Yes |
| Brand Name: | UNI-T |
| Continuity Buzzer: | Yes |
| DC Current: | 200uA/2200uA/22mA/220mA/2.2A/10A ±(0.5%+10) |
| DC Voltage: | 220mV/2.2V/22V/220V/1000V ±(0.1%+2) |
| Dimensions: | 180mm X 87mm X 47 mm |
| Diode test: | Yes |
| Display Type: | Digital Display |
| DIY Supplies: | Electrical |
| Duty Cycle: | Yes |
| Item: | UNI-T Digital Multimeter |
| LCD Backlight disply Expect UT61E: | Yes |
| Measuring Capacitance Range: | 22nF/220nF/2.2uF/22uF/220uF/2.2mF/22mF/220mF ±(3.0%+5) |
| Measuring Inductance Range: | Normal |
| Measuring Resistance Range: | 220Ω/2.2KΩ/22KΩ/220KΩ/2.2MΩ/22MΩ/220MΩ ±(0.5%+10) |
| mF capacitance measurement: | Yes |
| Model Number: | UT61A B C D E |
| Operating Mode: | A/M |
| Operating Temperature: | 0 - 40 ℃ |
| True RMS: | Yes |
