Terminal MCP 1.5K hembra para sec. cable 0.50-1.00 mmq

Código ErreBi: 45633 Código productor: 1241374-1 Productor: TE/Connectivity Embalaje: 5 piezas Nota: Cantidad 1 corresponde a 5 piezas Product Type Features - Sealable: No - Primary Locking Feature: Locking Lance - Wire Type: Copper - Receptacle Style: 180° Contact Features - Crimp Type: F-Crimp - Typical Current Rating (A): 12 - Terminal & Splice Type: Receptacle - Mating Tab Width: 1.5 mm [ .059 in ] - Mating Tab Thickness: .6 mm [ .024 in ] - Interface Plating: Tin (Sn) - Contact Termination Area Plating Material: Tin (Sn) Termination Features - Termination Method: Crimp Dimensions - Wire Size (mm²): .5 – 1 - Wire Insulation Diameter: 1.4 – 2.1 mm [ .055 – .083 in ] Usage Conditions - Operating Temperature Range: -40 – 130 °C [ -40 – 266 °F ] Industry Standards - Agency/Standard: LV214 Other - Terminal Transmits: 0 – 24 A (Low Power) Scheda Tecnica Serie: MCP Amperaje: 12A Temperatura de funcionamiento: -40°C a +130°C Material de contacto: Cobre Montaje: En cable Rango de cable:
