Solar Panel Power Supply Management Module 6V-24V Solar Charging Regulated Charger

Feature 1 Support MPPT maximum power point tracking function which can greatly improve solar energy conversion efficiency2 Support solar panel power adapter USB multiple charging methods3 Applicable to 6V 24V solar panels can be connected through DC 002 power socket or terminal block4 On board MPPT SET setting switch switch to the gear close to the input voltage the charging efficiency is higher5 On board pin header and USB two port 5V voltage output interface for user convenience6 On board high capacity aluminum electrolytic capacitors and chip ceramic capacitors reduce ripple and work more stably7 Onboard 14500 battery holder and PH2 0 battery socket for easy access to a variety of 3 7V lithium batteries8 Onboard multiple status indicators for easy viewing of solar panels and battery status9 On board over charge over discharge anti reverse over temperature over current protection circuit stable and safeParameter Solar panel input voltage SOLAR IN 6V 24VMicro USB input voltage USB IN 5VPin header USB output USB OUT 5V 1ACharge cut off protection voltage 4 2V1 Over discharge protection voltage 2 9V1 Solar panel charging efficiency about 78 USB charging efficiency about 82 3 7V battery boost output efficiency about 86 Maximum quiescent current 2mAWorking temperature 40C 85CSize 65 2mm56 2mm22 9mmPackage includes 1 x Power supply boardInterface Introduction 1 Solar charging interfaceCan be connected to the solar pan
