Schneider SR2E201B PLC Zelio Logic Compact Smart Relays, White

Range of product Zelio Logic product or component type Compact smart relay Complementary local display Without number or control scheme lines 0…240 with ladder programming 0…500 with FBD programming cycle time 6…90 ms backup time 10 years at 25 °C clock drift 12 min/year at 0…55 °C 6 s/month at 25 °C checks Program memory on each power up [Us] rated supply voltage 24 V AC supply voltage limits 20.4…28.8 V supply frequency 50/60 Hz maximum supply current 233 mA (without extension) power consumption in VA 6 VA without extension isolation voltage 1780 V protection type Against inversion of terminals (control instructions not executed) discrete input number 12 discrete input voltage 24 V AC discrete input current 4.4 mA discrete input frequency 47.53 Hz 57.63 Hz voltage state 1 guaranteed >= 14 V for discrete input voltage state 0 guaranteed = 2 mA (discrete input) current state 0 guaranteed = 10 mA at 12 V (relay output) operating rate in Hz 0.1 Hz (at Ie) for relay output 10 Hz (no load) for relay output mechanical durability 10000000 cycles for relay output [Uimp] rated impulse withstand voltage 4 kV EN/IEC 60947-1 and EN/IEC 60664-1 clock With response time 50 ms with ladder programming (from state 0 to state 1) for discrete input 50 ms with ladder programming (from state 1 to state 0) for discrete input 50.255 ms with FBD programming (from state 0 to state 1) for discrete input 50.255 ms with FBD programming (from state 1 to state 0) for discrete input 10 ms (from state 0 to state 1) for relay output 5 ms (from state 1 to state 0) for relay output connections - terminals Screw terminals, 1 x 0.2.1 x 2.5 mm² (AWG 25.AWG 14) semi-solid Screw terminals, 1 x 0.2.1 x 2.5 mm² (AWG 25.AWG 14) solid Screw terminals, 1 x 0.25.1 x 2.5 mm² (AWG 24.AWG 14) flexible with cable end Screw terminals, 2 x 0.2.2 x 1.5 mm² (AWG 24.AWG 16) solid Screw terminals, 2 x 0.25.2 x 0.75 mm² (AWG 24.AWG 18) flexible with cable end tightening torque 0.5 N.m overvoltage category III conforming to EN/IEC 60664-1 net weight 0.35 kg Environment immunity to micro breaks 10 ms repeated 20 times product certifications UL CSA C-Tick GL GOST standards EN/IEC 61000-4-12 EN/IEC 61000-4-11 EN/IEC 61000-4-6 level 3 EN/IEC 61000-4-3 EN/IEC 61000-4-5 EN/IEC 60068-2-27 Ea EN/IEC 61000-4-2 level 3 EN/IEC 61000-4-4 level 3 EN/IEC 60068-2-6 Fc IP degree of protection IP20 (terminal block) conforming to IEC 60529 IP40 (front panel) conforming to IEC 60529 environmental characteristic EMC directive conforming to EN/IEC 61000-6-2 EMC directive conforming to EN/IEC 61000-6-3 EMC directive conforming to EN/IEC 61000-6-4 EMC directive conforming to EN/IEC 61131-2 zone B Low voltage directive conforming to EN/IEC 61131-2 disturbance radiated/conducted Class B conforming to EN 55022-11 group 1 pollution degree 2 conforming to EN/IEC 61131-2 ambient air temperature for operation -20…40 °C in non-ventilated enclosure conforming to IEC 60068-2-1 and IEC 60068-2-2 -20…55 °C conforming to IEC 60068-2-1 and IEC 60068-2-2 ambient air temperature for storage -40…70 °C operating altitude 2000 m maximum altitude transport 3048 m relative humidity 95 % without condensation or dripping water Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Weight 329 g Package 1 Height 6.8 cm Package 1 width 10 cm Package 1 Length 13.5 cm Unit Type of Package 2 S03 Number of Units in Package 2 20 Package 2 Weight 7.069 kg Package 2 Height 30 cm Package 2 width 30 cm Package 2 Length 40 cm Offer Sustainability Sustainable offer status Green Premium product Reach Regulation Reach Declaration EU RoHS Directive Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration Mercury free Yes RoHS exemption information Yes China RoHS Regulation China RoHS declaration Environmental Disclosure Product Environmental Profile Circularity Profile End of Life Information WEEE The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins PVC free Yes
