SCOTT 24" Kid's Scale Rigid Bike - Yellow

The SCOTT Scale 24 Disc is our truly functional bike for kids who like to race. With suspension and disc brakes this bike is made for racers.Please note that bike specifications are subject to change without prior notice.
SPECIFICATIONS
FRAME
JR24 Rigid DiscAlloy 6061 / Semi int. HTSCOTT dropout / IS
FORK
AL-6061 rigid fork / IS
REAR DERAILLEUR
Shimano RD-TX800 Tourney8 Speed
SHIFTERS
Shimano SL-RS45-8RRevo Shifter
CRANKSET
Prowheel / Alloy Crank 140mm32T / w/CG PVG double cover
BB-SET
Feimin / BB68 / cartridge / square taper
CHAIN
KMC Z8.3
CASSETTE
SunRace CSM558 Speed / 11-34T
BRAKE LEVERS
Tektro TS325A
BRAKES
Tektro SCM-02Mech. Disc Brake / 160mm rotor
HANDLEBAR
Junior Flat-Bar / Alloy560mm / Syncros Youth 100/80 Grip
H'STEM
LEADTEC LCS-713050mm / 25.4mm clamp
SEATPOST
Alloy / 26.8mm / 300mm
SEAT
Syncros Future Pro
HEADSET
Feimin FP-H807, 1 1/8" Semi Int.
HUB (FRONT)
Formula DC-19-F / QR
HUB (REAR)
Formula DC-25-8-R / QR
SPOKES
15g / UCP / black
RIMS
Alex C-1000 Disc
FRONT TIRE
Kenda K1227 Booster / 24x2.4" / 30TPI
REAR TIRE
Kenda K1227 Booster / 24x2.4" / 30TPI
PEDALS
MARWI SP-700 / w/Reflector
EXTRAS
Kickstand
ACCESSORIES
Syncros Stem Protector
APPROX WEIGHTS IN KG
10.20
APPROX WEIGHTS IN LBS
22.49
MAX. SYSTEM WEIGHT
50 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
INCHES
24"
A
HEAD TUBE ANGLE
69.0 °
B
HEAD TUBE LENGTH
4.7 IN
C
TOP TUBE HORIZONTAL
19.7 IN
D
STANDOVER HEIGHT
E
BB OFFSET
-1.6 IN
F
BB HEIGHT
-1.6 IN
G
WHEEL BASE
38.9 IN
H
BB CENTER TO TOPTUBE CENTER
10.2 IN
I
BB CENTER TO TOP OF SEATTUBE
12.2 IN
J
SEAT ANGLE
73.5 °
K
CHAINSTAY
16.3 IN
L
REACH
14.0 IN
M
STACK
19.1 IN
N
STEM LENGTH
0
TRAIL
SIZE CHART
