S150 GSM/3G/4G SMS Industrial Alarm Automation Controller IOT RTU Alarm Controller S150 (8DIN,2DOUT)
Technical Details
| Alarm Type: | SMS,Apps Control |
| Arming Type: | APP |
| Brand Name: | KING PIGEON |
| Connection Type: | Wireless |
| DC Power supply: | Standard Adapter: DC 12V/1A Range 9~36VDC |
| Digital Input: | 8 (NO/NC/EOL) Compatible with Wet Contact , Reverse protection |
| Display: | No |
| External Antenna: | SMA Antenna interface, 50 Ohm |
| GSM/3G Frequency: | 2G/3G/4G |
| Installation: | 35mm standard DIN rail(Optional) Wall mount (Default) |
| Model Number: | S150 |
| Output Number: | 2 |
| Password Keyboard: | No |
| Power: | 12-24V |
| Power Consumption: | Standby:12V/70mA; WorkingMax.:12V/300mA |
| Relay Output: | 2 (7A@125VAC 5A@125VAC 20A@14VDC) |
| Serial Interface: | 1 USB Port |
| SIM interface: | Supporting 3V SIM Card |
| Siren Output: | 1 |
| Video Interface: | No |
| Zone Number: | 1 |
