RGBlink D4 4K Professional Presentation Switcher/Scaler with HDMI Input Module

With standard in and any out, D4 is so much more than a 4K scaler, Whether for scaling, presentation switching, 4K distribution or broadcast, D4 an ideal solution. There are multiple operation modes on board making D4 is a very flexible solution across a range of applications. Truly an All-In-One solution, D4 accepts a wide range of input signals in a huge array of formats - Inputs can be converted, scaled, transcoded to standard to HDMI 2.0 outputs or output to optional ports including DisplayPort. The dual channel 4K output scalers offer 12bit processing and YUV4:4 4 color space. Fully modular, D4 is modern presentation switching on demand.The standard in multi-format 4K presentation switchingD4 is a very flexible video switching and scaling solution for 4K signals featuring multiple output modes, a comprehensive on board feature set and acclaimed RGBlink modular design. Truly multi-signal, D4 may be fitted with a wide range of input signals including HDMI 2.0m DisplayPort 1.2 and 12G-SDI along with conventional 2K signals.In the tradition of previous generation 2K solutions signals can be converted, scaled, transcoded to 4K output. Dual channel 4K HDMI 2.0 output are standard while these two channels may be duplicated for output via the option slot. There is full 4:4:4 color space,12 bit on board processing and support for HDR signals to meet the highest performance standards. EDID management is built in and D4 is also HDCP 2.X compliant. Across a range of applications requiring scan conversion, scaling or seamless presentation switching, D4 is ideal for high performance and broadcast workloads.Standard ModeBoth output channels are duplicated offering the same output as program and monitor. PIP's are available in this mode with PiP/layer count dependent on output resolution and layer arrangement.Presentation Mode Up to three 4K inputs may be used as PIPs over a 4K background video source.Independent (Dual 4K) ModeEach of output channels separately configured for image, resolution, scale and other attributes.Splicing ModeOutput channels are utilized to stitch or splice input source(s) to create large seamless fully synchronized display surfaces.Switcher (Preview) ModeBoth outputs are set to the same resolution, whether 2K or 4K, with one channel serving as program (PGM), and the other channel as preset preview (PST) for full seamless alpha switching been preset and programme. All adjustment made on PST prior to switching to live PGM display output.HDRSignals with High Dynamic Range are supported for processing via the processor with high bandwidth and wide gamut 12bit gray level processing.FormatD4 accepts all common 2K & 4K input formats, with EDID management built in. Output to any 2K or 4K format with custom resolutions able to be specified to down stream requirements.Visual EnhancementsApply a range of visual effects and enhancements with fine grain controls.Rotation & FlipSupport image rotation and flip including horizontal and vertical flip/mirror.Crop & PositionSelect X and Y offsets along with width and height to select any image part for output.ScaleScale output(s) to any size within the selected resolution range.Output SplicingSplit output across the dual output channels providing an 8K x 2K display canvas and seamless pixel to pixel hard edge blend.
