OWON SDS1102 7" LCD Oscilloscope 2-Channel Digital Oscilloscopes 100MHZ Bandwidth 1GS/s High Accuracy Oscilloscope

Features This is a super economical type digital storage oscilloscope The 2 channel oscilloscope has 100MHz bandwidth 1GS s smple rate Ultra thin body designed with 7 inch high resolution LCD Support for SCPI and for LabVIEW Application for electronic circuit debugging circuit testing design and manufacture education and training automobile maintenance and testing Specification ModelSDS1102Bandwidth100MHzSample Rate1GS SHorizontal Scale s div 5ns div 1000s div step by 1 2 5Rise Time at input typical 3 5nsChannel2DisplayT color LCD 800x 480 pixelsInput Impedance1MΩ ± 2 in parallel with 20pF±5pFChannel Isolation50Hz 100 1 10MHz 40 1Max Input Voltage400V PK PK DC AC PK PK DC Gain Accuracy± 3 Record Length10KDC Accuracy average Average16 ± 3 reading 0 05 div for VProbe Attenuation Factor1X 10X 100X 1000XLF Respond AC 3dB ≥10Hz at input AC coupling 3dB Sample Rate Relay TimeAccuracy±100ppmInterpolationsin x xInterval T Accuracy full bandwidth Single ± 1 interval time 100ppmx reading 0 6ns Averagel6 ± 1 interval time 100ppmx reading 0 4ns Input CouplingDC AC and GNDVertical Resolution A D B bits 2channels simultaneously Vertical Sensitivity2mV div 10V div at input Trigger TypeEdge VideoTrigger ModeAuto Normal and SingleTrigger Leveldivisions from screen centerLine Field Frequency video NTSC PAL and SECAM standardCursor MeasurementV and T between cursorsAutomatic MeasurementVpp Vavg RMS Frequency Peri
