OWON HDS25/HDS25S 25MHz Dual Channel Oscilloscope with Multimeter 250MSa/s Sampling Rate LCD Display Waveform Generator

1111MicrosoftInternetExplorer402DocumentNotSpecified7 8 磅Normal0Specifications Oscilloscope Specifications Model HDS25 HDS25S Bandwidth 25MHz Channel 2 Sample Rate 250MSa s Single channel 125MSa s Dual channel Acquisition Model Sample Peak detect Record Length 8K or 4K optional Display 3 5 inch LCD Waveform Refresh Rate 10 000 wfms s Input Coupling DC AC Ground Input Impedance DC Coupling 1 MΩ±2 in parallel with 16 pF±10 pF Probe Attenuation 1X 10X 100X 1000X 10000X Max Input Voltage 400V DC AC PK PK Sensitivity Resolution 10mV div 10V div Vertical Resolution 8 bit Horizontal Scale 5ns div 1000s div 1 2 5 step Trigger Type Edge Trigger Model Auto Normal Single Automatic Measurement Period Frequency Mean PK PK Max Min Amplitude RMS Cursor Measurement ΔV ΔT ΔTΔV between cursors auto cursor Digital Multimeter Specification Full Scale Reading 4 ½ digits max 20000 counts Testing Modes Voltage Current Resistance Capacitance Diode Continuity Max Input Voltage AC 750V DC 1000V Max Input Current AC 10A DC 10A Automatic Range Yes True RMS Yes Waveform Generator Specification only for HDS25S Frequency Output Sine 0 1Hz 10MHz Square 0 1Hz 2MHz Ramp 0 1Hz 1MHz Pulse 0 1Hz 5MHz Arbitrary Waveform 0 1Hz 5MHz Amplitude 50Ω 0 01Vpp 2 5Vpp Sample Rate 125MSa s Waveform Length 8K Vertical Resolution 14 bits Features 1 High Display Refresh Rate The 10 000 wfms
