Lowell Manufacturing LGTR 54U 32" Depth Gangable Tall Rack with Rear Door, Black
Extra tall (54U) gangable rack with adjustable rails is fully welded 16-gauge steel with 14-gauge base, reinforced at all load-bearing junctions. Fully welded certified U.S. steel, 16- gauge frame with seamless side frame construction, 14-ga. top and 14-ga. bottom reinforced at load-bearing junctions for robust support, strength equivalent to 11-ga. steel. Black wrinkle powder epoxy finish. Beveled edge corners front and rear. Front Frame nutserts are ready to add optional surface-mount door (left or right swing). Order front door separately. Rear Removable knockout panel in frame above and below door. Combination EKOs for conduit (1/2"- 3/4" and 1"-1-1/2") and KOs for wireless antennae (1/2"). Standard model includes recessed rear door with key lock (left or right swing). Rear door can be omitted by placing "LRD" (less rear door) suffix in model no. Sides (open access) Obround openings along base for cabling between racks. Optional side panel increases overall width 1" per side. Configurable Top (with closure panels) 10U opening features riveted 10-32 threaded rails on 19" E.I.A. spacing. Includes two black closure panels (3U, 7U) which can be replaced with optional 19" panels (fan, vent, etc.). Bottom (open access) Includes 10-32 threaded grounding stud in corner, 3/8"-16 threaded T-nuts for (optional) leg levelers and holes for anchor bolts (by others). Opening is 27.88"D x 18.89"W. Rails (fully adjustable) Two pairs of 11-ga. steel 10-32 threaded rails on E.I.A. spacing with numbered RU increments (rails mount in either direction). Black finish. Clearance for wire management from front rail to outside frame (1.5") and from front rail to (optional) surface-mount door (2.25"). Hardware Black pilot point screws with captive washers for quick installation. Compliance EIA/TIA compliant. RoHS compliant. UL 2416 Listed in U.S.A. and Canada.
