Kramer Electronics HDBT-OUT2-F16 2-Ch HDMI over Extended Reach HDBT Output Card

HDBT-OUT2-F16 is a two-channel HDMI, bidirectional RS-232, Ethernet & IR over HDBaseT twisted pair transmitter card for the VS-1616 Series Modular Multi-Format Digital Matrix Switchers. The HDBT-OUT2-F16 outputs two extended reach HDBaseT signals with bidirectional RS-232, IR and Ethernet from the chassis to the line.• 3D Pass-Through Max. Data Rate 6.75Gbps (2.25Gbps per graphic channel). HDBaseT Technology HDTV compatible, HDCP compliant. System Range Up to 130m (430ft) normal mode; up to 180m (590ft) ultra-mode (1080p at 60Hz at 24bpp). Note: When using Kramer HDBaseT cables. Ethernet Extension Ethernet interface data flows in both directions, allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control. Bidirectional RS-232 Extension Serial interface data flows in both directions, allowing data transmission and device control. Bidirectional Infrared Extension IR interface data flows in both directions, allowing remote control of peripheral devices located at either end of the extended line. Applications • Professional display systems requiring video signal routing• Broadcast, presentation and production facilities, as well as monitoring in large duplication systems• Rental and staging
