Holybro Tekko32 F4 Metal 65A Blheli_32 4-6S 4 IN 1 Brushless ESC 30.5x30.5mm for RC Drone FPV Racing

Features F4 MCU BLHELI32 Metal case mosfet PWM output 96K 4 6SThe New BLHELI32 ESC adapted the F4 MCU which will provide a smoother control and faster response speed Specification F4 MCU with BLHELI32 firmwareMaximum PWM output upto 96K default 48K Amperage meter scale ratio has been adjusted to 168 The 4in1 has onboard analog current sensor and TLM function then no current reading over TLM Uses metal case mosfet for better heat dissipationNo output BECSupports Lipo 4 6SExtra capacitor needed for 6s 1000uf 35v for 6s usage Dimensions 43 x 44mmMounting holes 30 5 30 5mm M4 Weight 15 8gNotice The air flow is very important if you want to run this 4in1 in high current The input cable from Lipo to 4in1 should be at least 12AWG and well soldered Package Included 1x Tekko32 F4 Metal 4in1 65A ESC 4x M3 Anti Vibration Silicone Grommet Insert 1x Electrolytic capacitor 1000uF 35v 1x 8pin to 8pin 1mm pitch 65mm cable 1x 8pin to 8pin 1mm pitch 25mm cable Downloads Tekko32 F4 Metal 4in1 ESC 65A SPEC V1 4 Some Tips BLHeli 32 ESC Firmware OverviewGitHub
