Geekcreit® DIY 32V 4 Channel Jog/Inching And Self-locking + 433MHz Receiver Module + APP Remote Control For WIFI Wireles

Description WIFi control model no need to program No matter where you are you only need to download a APP to connect the wifi and control the cloud Features 1 With signal instruction light and relay pull on instruction light2 Power1W and quiescent current 80mA3 Cutover current 10A Cutover voltage 250V4 10A Relay Model5 The life of Relay Model is more than 1 000 0006 Insulation resistance 100M7 Maximum pull on time 15mS8 Maximum release time 5mS9 Working Temperature 40 to 70degree10 Working Humidity 40 to 80 RHFunction 1 Default inching Function Press the open relay by mobile phone then cut off the pull on imediately default one second it has the timing share function at the same time 2 Self locking when press the inching and locking button with the light on Press open relay to pull on press close relay to cut off Receiver Features 1 Receiver sensitivity 110dBm 2 Operating frequency 315MHz 433 92MHz 330MHz 390MHz 418MHz3 Power supply input range 3 3V 5 5V 4 Low power cosumption 5 0V 433 92MHz 3 8 4 1mA 5 0V 315MHz 2 5 2 8mA Manchester Encoding could last the transmited speed to 2 4K 5 Pin Description From left to right ANT GND LED SW VT D0 D1 D2 D3 VDD GND6 Working temperature range 30 85 ℃7 Good local oscillator radiation suppression receiver module could be worked in groups without any affect Remote Control Technical Parameters 1 Working voltage 12V23A Battery2 Operating Current 9mA3 Oscillation mode
