GPSDO GPS Disciplined Oscillator 10MHz Signal Source Positioning SystemSquare Waves with NE0-6M Module

Specifications Power Voltage DC 12V±2V Operating Current 650mA during warm up stabilizing at 350mA Output Frequency 10 000000 000MHz ±0 01Hz Output Waveform Square Waves Output Amplitude 10dBm Oven Controlled Crystal ISOTEMP OCXO 143 141 Global Positioning System Module NE0 6MFeatures 1 Introducing Global Positioning System Disciplined Oscillator also known as a Global Positioning System disciplined over controlled crystal oscillator Global Positioning System disciplined clock or 10MHz standard signal source Compared to conventional time bases it boasts superior precision minimal temperature drift and unparalleled output stability 2 Leveraging the precise 1PPS signal from Global Positioning System our microcontroller meticulously adjusts and outputs a 16 Bit PWM signal to meticulously control the oven controlled crystal oscillator s precision The fine tuning voltage for the crystal oscillator ranges from 0 5V where each 1Bit PWM increment precisely adjusts the output voltage by 0 000076V 3 Measuring 150 88 38mm in dimensions excluding protrusions the front panel integrates a display screen and an encoder for easy operation The rear panel is equipped with a 10MHz output interface a 1PPS output interface a Global Positioning System antenna connector along with power switch and a 12V DC power input jack Ideal Applications This is perfect for high end audio decoders instruments meters frequency counters signal generators and any device r
