GM811 Series DC5V USB/UART Interface Qr Code Scanner Bar Code Reader Support Windows PDF417 Scanner Module D

Sensor:CMOS Scan Mode:640*480 Lighting:White LED Power On:Green LED IndicatorLight:Blue LED Read Code Type 1D: -13 -8 -A -EISSN CodaBar Code 128 Code93 ITF-14 ITF-6 Interleaved 2 of 5 Industrial2of5 Matrix2of5 Code 39 Code11 -Plessey GS1 Composite GS1-Databar (RSS) 2D: QRCode DataMatrix PDF417 GM811-L Reading Distance:7-50cm *: 25% Scan Angle**:Roll:360°Pitch:65°Yaw:65° Viewing Angle:67°(Horizontal)53°(Vertical) Accuracy of reading*: 10mil Mechanical/electrical Parameters: Interface:TTL-232/USB Size(mm):50x50 mm Weight:68g Prompting mode:Buzzer LED Indicator OperatingVoltage:5V Operation Current: less than 70mA Continuous Reading Current: less than 120mA Standby Current: less than 6mA(Typical) Startup time: less than 250mS (Typical) Environmental Parameters: Operatingtemperature:-20℃~+60℃ Storage Temperature:-40℃~+70℃ Operating Humidity:5%~95%(Non-Condensing) Environmental Light:Normal indoor Fall:Withstand 1.2 m drop on concrete floor (50 1.2 m drop on concrete floor repeatedly) type:D Colour:As Shown Material:Metal Package Contents: 1 x Scanner Module Only the above package content other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
